Quad beams wired Active Infrared Detector outdoor 150m

  • Quad beams wired Active Infrared Detector outdoor 150m

Quad beams wired Active Infrared Detector outdoor 150m

Price :
$48.50
Add to Cart:
  • Model: ABH-150
  • Shipping Weight: 2kgs
  • 50 Units in Stock

DESCRIPTION

Indoor and outdoor used 4 beams digital infrared detector
Functions and Specification:
1.Adopts large-caliber conjoined aspherical lens. Highly focused infrared with longer detecting distance.
2.Anti-glare interference, lighting protection circuit design.
3.Quad beams simultaneously blocked inspection.
4.Detachable sighting telescope
5.Dew and frost proof solution: heating housing
6.Beams:4 Beams
7.Outdoor detecting distance:150m, indoor detecting distance:450m
8.Response speed:50-700msec adjustable
9.Alarm output:1C relay contact output, contact capability DC30V/0.5A MAX
10.Power and voltage:DC13.8~24V,AC11~18V
11.Operation current: 100mA max
12.Working temperature:-25℃~55℃
13.Tamper output:1Bcontact output,DC30V/0.5A MAX
14.Optical axis adjust angle(horizontal):180°(±90°)
15.Optical axis adjust angle(vertical):20°(±10°)
16.Dimension:35*9.9*10.4mm each
17.Weight:970g for each of transmitter and receiver
